ORACLE有DATA GUARD(ADG)、EXPDP/IMPDP、RMAN、存储这四种迁移方式。
因为原数据库有28TB数据量,业务不接受停机时间过长,无法使用EXPDP/IMPDP、RMAN、存储方式完成数据库迁移,所以本次迁移使用ADG方式迁移数据库。
迁移过程
主库环境
操作系统:Red Hat 7.8
Oracle和grid版本 :19.11.0.0.210420
数据库架构:RAC
存储:ASM
备库环境
操作系统:Red Hat 7.9
Oracle和grid版本:19.11.0.0.210420
数据库架构:单机
SQL> archive log list;
Database log mode Archive Mode
Automatic archival Enabled
Archive destination +ARCH
Oldest online log sequence 207743
Next log sequence to archive 207746
Current log sequence 207746
主库已经启归档模式,如果未启用需要先启用归档模式。
SQL> select force_logging from v$database;
FORCE_LOGGING
---------------------------------------
YES
主库已开启强制日志,如果没有启用则需要开启,开启后需要做一次数据库全备,在用NBU恢复时也需要用最新的全备进行恢复。
alter system set log_archive_config=DG_CONFIG=(orcl,orcladg) scope=both;
alter system set log_archive_dest_1=LOCATION=+ARCH valid_for=(all_logfiles,all_roles) db_unique_name=orcl scope=both;
alter system set log_archive_dest_2=SERVICE=orcladg lgwr sync valid_for=(online_logfile,primary_role) db_unique_name=orcladg scope=both;
alter system set log_archive_dest_state_2=defer scope=both;
alter system set fal_client=orcl scope=both;
alter system set fal_server=orcladg scope=both;
alter system set standby_file_management=auto scope=both;
SQL> select THREAD#,BYTES/1024/1024 from v$log;
THREAD# BYTES/1024/1024
---------- ---------------
1 1024
1 1024
2 1024
2 1024
查询日志组数量和路径:
col MEMBER for a80;
col TYPE for a10;
set lin240 pages999;
select * from v$logfile;
GROUP# STATUS TYPE MEMBER IS_ CON_ID
------ ------ ------ ----------------------------------------- --- -------
1 ONLINE +DATA/ORCL/ONLINELOG/group_1.258.1061077801 NO 0
2 ONLINE +DATA/ORCL/ONLINELOG/group_2.259.1061077801 NO 0
3 ONLINE +DATA/ORCL/ONLINELOG/group_3.270.1061083275 NO 0
4 ONLINE +DATA/ORCL/ONLINELOG/group_4.271.1061083275 NO 0
alter database add standby logfile thread 1 group 5 +DATA size 1024m;
alter database add standby logfile thread 1 group 6 +DATA size 1024m;
alter database add standby logfile thread 1 group 7 +DATA size 1024m;
alter database add standby logfile thread 2 group 8 +DATA size 1024m;
alter database add standby logfile thread 2 group 9 +DATA size 1024m;
alter database add standby logfile thread 2 group 10 +DATA size 1024m;
create pfile=/tmp/init.ora from spfile;
scp /tmp/init.ora 备库IP:/oracle/app/oracle/product/19.0.0/db/dbs/initorcl.ora
*.audit_file_dest=/oracle/app/oracle/admin/orcl/adump
*.audit_trail=NONE
*.cluster_database=FALSE
*.compatible=19.0.0
*.control_files=+data/ORCL/CONTROLFILE/xxxx
*.db_block_size=8192
*.db_cache_size=60129542144
*.db_create_file_dest=+DATA
*.db_domain=
*.db_files=2000
*.db_name=orcl
*.db_unique_name=orcldg
*.diagnostic_dest=/oracle/app/oracle
*.dispatchers=(PROTOCOL=TCP) (SERVICE=orclXDB)
*.event=28401 trace name context forever,level 1
*.java_jit_enabled=TRUE
*.fal_client=orcldg
*.fal_server=orcl
*.log_archive_config=DG_CONFIG=(orcldg,orcl)
*.log_archive_dest_1=LOCATION=+arch
*.log_archive_dest_3=SERVICE=orcl lgwr sync valid_for=(online_logfile,primary_role) db_unique_name=orcl
*.log_archive_dest_state_2=ENABLE
*.open_cursors=1000
*.parallel_max_servers=128
*.parallel_min_servers=32
*.parallel_servers_target=128
*.pga_aggregate_target=27068989440
*.processes=3000
*.remote_login_passwordfile=exclusive
*.service_names=orcl
*.session_cached_cursors=200
*.sessions=3305
*.sga_target=100G
*.standby_file_management=auto
*.undo_retention=3600
*.undo_tablespace=UNDOTBS1
cd /oracle/app/oracle/product/19.0.0/dbhome_1/dbs
scp orapworcl1 备库IP:/oracle/app/oracle/product/19.0.0/db/dbs/orapworcl
scp orapworcl1 节点2IP:/oracle/app/oracle/product/19.0.0/db/dbs/orapworcl2
SQL> alter database create standby controlfile as /tmp/standby.ctl;
scp /tmp/standby.ctl 备库IP:/tmp/standby.ctl;
rman target /
startup pfile=/oracle/app/oracle/product/19.0.0/db/dbs/initorcl.ora nomount;
RMAN> restore standby controlfile to +DATA FROM /tmp/standby.ctl;
mkdir -p /oracle/app/oracle/admin/orcl/adump
ORCLDG =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST = 备库IP)(PORT = 1521))
(CONNECT_DATA =
(SERVER = DEDICATED)
(SERVICE_NAME = orcl)
)
)
ORCL =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST = 节点1IP)(PORT = 1521))
(ADDRESS = (PROTOCOL = TCP)(HOST = 节点2IP)(PORT = 1521))
(CONNECT_DATA =
(SERVER = DEDICATED)
(SERVICE_NAME = orcl)
)
)
ORCLDG =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST = 备库IP)(PORT = 1521))
(CONNECT_DATA =
(SERVER = DEDICATED)
(SERVICE_NAME = orcl)
)
)
lsnrctl start
主备库添加白名后reload监听:
reload
Tnsping测试:
tnsping ORCL
tnsping ORCLDG
vi nbu_rman.sh
#!/bin/bash
source /home/oracle/.bash_profile
rman target / < run{
ALLOCATE CHANNEL c0 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
ALLOCATE CHANNEL c1 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
ALLOCATE CHANNEL c2 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
ALLOCATE CHANNEL c3 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
ALLOCATE CHANNEL c4 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
ALLOCATE CHANNEL c5 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
restore database;
recover database;
RELEASE CHANNEL c0;
RELEASE CHANNEL c1;
RELEASE CHANNEL c2;
RELEASE CHANNEL c3;
RELEASE CHANNEL c4;
RELEASE CHANNEL c5;
}
EOF
SQL> alter system set log_archive_dest_state_2=enable scope=both;
alter database recover managed standby database using current logfile disconnect from session;
PR00 (PID:112926): FAL: Failed to request gap sequence
PR00 (PID:112926): GAP - thread 1 sequence 211212-211250
PR00 (PID:112926): DBID 1915883988 branch 1085828161
PR00 (PID:112926): FAL: All defined FAL servers have been attempted
PR00 (PID:112926): -------------------------------------------------------------------------
PR00 (PID:112926): Check that the CONTROL_FILE_RECORD_KEEP_TIME initialization
PR00 (PID:112926): parameter is defined to a value thats sufficiently large
PR00 (PID:112926): enough to maintain adequate log switch information to resolve
PR00 (PID:112926): archived redo log gaps.
PR00 (PID:112926): -------------------------------------------------------------------------
如果存现主库和NBU缺失部分归档文件无法完成在备库应用,可以选择主库最新的全备文件重新进行恢复。
RMAN> configure CHANNEL device type SBT_TAPE PARMS ENV=
(NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx);
RMAN> list backup of archivelog all;
RMAN> catalog device type SBT_TAPE backuppiece arch_xxxx1;
RMAN> catalog device type SBT_TAPE backuppiece arch_xxxx2;
RMAN> CONFIGURE CHANNEL DEVICE TYPE SBT_TAPE CLEAR;
run {
ALLOCATE CHANNEL c0 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
ALLOCATE CHANNEL c1 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
restore archivelog sequence between xxxx1 and xxxx8;
RELEASE CHANNEL c0;
RELEASE CHANNEL c1;
}
run{
ALLOCATE CHANNEL c1 TYPE SBT_TAPE SEND NB_ORA_SERV=NBUmaster,NB_ORA_CLIENT=xxxx,NB_ORA_DISK_MEDIA_SERVER=xxxx;
restore archivelog sequence between xxxx2 and xxxx6 thread 2;
RELEASE CHANNEL c1;
}
alter database recover managed standby database cancel;
alter database open;
alter database recover managed standby database using current logfile disconnect from session;
SQL> select OPEN_MODE from v$database;
OPEN_MODE
--------------------
READ ONLY WITH APPLY
以上状态说明ORACLE ADG搭建成功。
alter database recover managed standby database cancel;
shutdown immediate;
startup mount;
alter database flashback on;
alter database open;
alter system set log_archive_dest_state_2=defer;
select open_mode from v$database;
OPEN_MODE
--------------------
READ ONLY
alter database activate standby database;
