python深度神经网络tensorflow练习好一点的实体模型开展图像分类

89542767 / 417人阅读

  此篇文章主要是给大家介绍了python深度神经网络tensorflow练习好一点的实体模型开展图像分类实例详细说明,感兴趣的小伙伴可以参考借鉴一下,希望可以有一定的帮助,祝愿大家多多的发展,尽早涨薪。


  文章正文


  Google在各类图象数据库系统ImageNet上练习好啦1个Inception-v3实体模型,这一实体模型大家也可以用来进去图像分类。


  下载地址:https://pan.baidu.com/s/1XGfwYer5pIEDkpM3nM6o2A


  提取码:hu66


  免费下载完缓解压力后,获得好多个文档:


  在其中


  classify_image_graph_def.pb文件便是练习好一点的Inception-v3实体模型。


  imagenet_synset_to_human_label_map.txt是类型文档。


  随机找一张图片


  对这张图片进行识别,看它属于什么类?


  代码如下:先创建一个类NodeLookup来将softmax概率值映射到标签上。


  然后创建一个函数create_graph()来读取模型。


  读取图片进行分类识别


</>复制代码

  1.   #-*-coding:utf-8-*-
  2.   import tensorflow as tf
  3.   import numpy as np
  4.   import re
  5.   import os
  6.   model_dir='D:/tf/model/'
  7.   image='d:/cat.jpg'
  8.   #将类别ID转换为人类易读的标签
  9.   class NodeLookup(object):
  10.   def __init__(self,
  11.   label_lookup_path=None,
  12.   uid_lookup_path=None):
  13.   if not label_lookup_path:
  14.   label_lookup_path=os.path.join(
  15.   model_dir,'imagenet_2012_challenge_label_map_proto.pbtxt')
  16.   if not uid_lookup_path:
  17.   uid_lookup_path=os.path.join(
  18.   model_dir,'imagenet_synset_to_human_label_map.txt')
  19.   self.node_lookup=self.load(label_lookup_path,uid_lookup_path)
  20.   def load(self,label_lookup_path,uid_lookup_path):
  21.   if not tf.gfile.Exists(uid_lookup_path):
  22.   tf.logging.fatal('File does not exist%s',uid_lookup_path)
  23.   if not tf.gfile.Exists(label_lookup_path):
  24.   tf.logging.fatal('File does not exist%s',label_lookup_path)
  25.   #Loads mapping from string UID to human-readable string
  26.   proto_as_ascii_lines=tf.gfile.GFile(uid_lookup_path).readlines()
  27.   uid_to_human={}
  28.   p=re.compile(r'[nd]*[S,]*')
  29.   for line in proto_as_ascii_lines:
  30.   parsed_items=p.findall(line)
  31.   uid=parsed_items[0]
  32.   human_string=parsed_items[2]
  33.   uid_to_human[uid]=human_string
  34.   #Loads mapping from string UID to integer node ID.
  35.   node_id_to_uid={}
  36.   proto_as_ascii=tf.gfile.GFile(label_lookup_path).readlines()
  37.   for line in proto_as_ascii:
  38.   if line.startswith('target_class:'):
  39.   target_class=int(line.split(':')[1])
  40.   if line.startswith('target_class_string:'):
  41.   target_class_string=line.split(':')[1]
  42.   node_id_to_uid[target_class]=target_class_string[1:-2]
  43.   #Loads the final mapping of integer node ID to human-readable string
  44.   node_id_to_name={}
  45.   for key,val in node_id_to_uid.items():
  46.   if val not in uid_to_human:
  47.   tf.logging.fatal('Failed to locate:%s',val)
  48.   name=uid_to_human[val]
  49.   node_id_to_name[key]=name
  50.   return node_id_to_name
  51.   def id_to_string(self,node_id):
  52.   if node_id not in self.node_lookup:
  53.   return''
  54.   return self.node_lookup[node_id]
  55.   #读取训练好的Inception-v3模型来创建graph
  56.   def create_graph():
  57.   with tf.gfile.FastGFile(os.path.join(
  58.   model_dir,'classify_image_graph_def.pb'),'rb')as f:
  59.   graph_def=tf.GraphDef()
  60.   graph_def.ParseFromString(f.read())
  61.   tf.import_graph_def(graph_def,name='')
  62.   #读取图片
  63.   image_data=tf.gfile.FastGFile(image,'rb').read()
  64.   #创建graph
  65.   create_graph()
  66.   sess=tf.Session()
  67.   #Inception-v3模型的最后一层softmax的输出
  68.   softmax_tensor=sess.graph.get_tensor_by_name('softmax:0')
  69.   #输入图像数据,得到softmax概率值(一个shape=(1,1008)的向量)
  70.   predictions=sess.run(softmax_tensor,{'DecodeJpeg/contents:0':image_data})
  71.   #(1,1008)-&gt;(1008,)
  72.   predictions=np.squeeze(predictions)
  73.   #ID--&gt;English string label.
  74.   node_lookup=NodeLookup()
  75.   #取出前5个概率最大的值(top-5)
  76.   top_5=predictions.argsort()[-5:][::-1]
  77.   for node_id in top_5:
  78.   human_string=node_lookup.id_to_string(node_id)
  79.   score=predictions[node_id]
  80.   print('%s(score=%.5f)'%(human_string,score))
  81.   sess.close()

  最后输出


  tiger cat(score=0.40316)


  Egyptian cat(score=0.21686)


  tabby,tabby cat(score=0.21348)


  lynx,catamount(score=0.01403)


  Persian cat(score=0.00394)


  综上所述,上述就给大家介绍完毕了,希望可以给大家带来帮助。
